My Tmux Setup: A Developer''s Terminal Multiplexer Configuration

Tmux is central to how I work. It looks good and gets things done. Here is my complete setup with configuration files, custom scripts, and why I made each choice.

Why Tmux?

Here is what tmux gives you:

• Persistent sessions. Your work survives terminal crashes and SSH disconnections.
• Multiple windows and panes. Organize your workspace in one terminal window.
• Session management. Jump between projects instantly.
• Remote pairing. Share terminal sessions with teammates.
• Scriptable. Automate your development environment setup.

Getting Started

You need a foundation. Follow these steps.

Install Tmux

MacOS users:

brew install tmux fzf

Linux users:

sudo apt install tmux fzf

Install TPM

The Tmux Plugin Manager handles plugins. Clone the repository.

git clone https://github.com/tmux-plugins/tpm ~/.tmux/plugins/tpm

Create Directories

Create the configuration and script directories.

mkdir -p ~/.config/tmux/scripts

Install Fonts

Status bar icons require a Nerd Font. Use JetBrains Mono Nerd Font. Install the font. Set the terminal font.

Configure Shell

Add the scripts directory to your PATH. Add this line to ~/.zshrc.

export PATH="$HOME/.config/tmux/scripts:$PATH"

Reload the shell configuration.

source ~/.zshrc

Apply Configuration

Create ~/.config/tmux/tmux.conf. Paste the code from the sections below.

Install Plugins

Start tmux. Press Ctrl+a then I. TPM installs the plugins.

The Configuration

My configuration lives at ~/.config/tmux/tmux.conf. Let me break it down section by section.

Core Settings

# Set true color support
set -g default-terminal "tmux-256color"
set -ag terminal-overrides ",xterm-256color:RGB"

# Enable mouse support
set -g mouse on

# Set prefix to Ctrl+a (more ergonomic than Ctrl+b)
unbind C-b
set -g prefix C-a
bind C-a send-prefix

# Start windows and panes at 1, not 0
set -g base-index 1
setw -g pane-base-index 1

# Renumber windows when one is closed
set -g renumber-windows on

# Increase history limit
set -g history-limit 50000

# Reduce escape time (for vim)
set -sg escape-time 0

# Enable focus events
set -g focus-events on

# Refresh status more often
set -g status-interval 5

Why these choices:

• Ctrl+a as prefix. My pinky thanks me. The default Ctrl+b forces an awkward hand position.
• 1-indexed windows. The keyboard number row starts at 1. Tmux windows should too.
• Zero escape time. Vim users need this. The default delay makes mode switching feel slow.
• Mouse support. Good for scrolling and resizing panes. Keeps the keyboard-first workflow.

Key Bindings

# Reload config
bind r source-file ~/.config/tmux/tmux.conf ; display-message "Config reloaded!"

# Split panes using | and -
bind | split-window -h -c "#{pane_current_path}"
bind - split-window -v -c "#{pane_current_path}"
unbind '"'
unbind %

# New window in current path
bind c new-window -c "#{pane_current_path}"

# Vim-style pane navigation
bind h select-pane -L
bind j select-pane -D
bind k select-pane -U
bind l select-pane -R

# Pane resizing with Shift + hjkl
bind -r H resize-pane -L 5
bind -r J resize-pane -D 5
bind -r K resize-pane -U 5
bind -r L resize-pane -R 5

# Quick window navigation
bind -r C-h previous-window
bind -r C-l next-window

# Swap windows
bind -r "<" swap-window -d -t -1
bind -r ">" swap-window -d -t +1

# Toggle last window
bind Space last-window

The idea: Make splits obvious. | for vertical. - for horizontal. Keep navigation vim-like. The -r flag enables key repeat. Hold the key to resize continuously.

Vim-like Copy Mode

setw -g mode-keys vi

# Enter copy mode with prefix + [
bind [ copy-mode

# Vim-like selection
bind -T copy-mode-vi v send -X begin-selection
bind -T copy-mode-vi y send -X copy-selection-and-cancel
bind -T copy-mode-vi Escape send -X cancel

# Copy to system clipboard (macOS)
bind -T copy-mode-vi y send -X copy-pipe-and-cancel "pbcopy"

Copying text feels natural if you use vim. Press prefix + [ to enter copy mode. Press v to start selection. Press y to yank to clipboard.

Status Bar (Catppuccin Theme)

I spent the most time on the status bar. I wanted something informative without clutter. I used the Catppuccin color palette.

set -g status-position top
set -g status-justify centre

# Status bar colors (Catppuccin-inspired)
set -g status-style "bg=#1e1e2e,fg=#cdd6f4"

# Left status: session + directory + git branch
set -g status-left-length 80
set -g status-left "#[fg=#1e1e2e,bg=#89b4fa,bold] #S #[fg=#89b4fa,bg=#45475a]#[fg=#cdd6f4,bg=#45475a] #{b:pane_current_path} #[fg=#45475a,bg=#1e1e2e]#[fg=#a6e3a1] #{?#{!=:#(git -C #{pane_current_path} rev-parse --abbrev-ref HEAD 2>/dev/null),}, #(git -C #{pane_current_path} rev-parse --abbrev-ref HEAD 2>/dev/null),}"

# Right status: battery + time + date
set -g status-right-length 80
set -g status-right "#(~/.config/tmux/scripts/battery.sh) #[fg=#45475a]#[fg=#cdd6f4,bg=#45475a] %H:%M #[fg=#89b4fa]#[fg=#1e1e2e,bg=#89b4fa,bold] %a %d %b "

# Window status
set -g window-status-format "#[fg=#6c7086] #I:#W "
set -g window-status-current-format "#[fg=#f9e2af,bold] #I:#W "
set -g window-status-separator ""

# Pane borders
set -g pane-border-style "fg=#45475a"
set -g pane-active-border-style "fg=#89b4fa"

# Message style
set -g message-style "bg=#f9e2af,fg=#1e1e2e"

What shows up:

• Left side: Session name, current directory, and git branch (with icon)
• Center: Window list with the current window highlighted in yellow
• Right side: Battery status, time, and date

The powerline-style arrows create visual separation between segments.

Battery Script

I wrote a custom script for the battery indicator. Save this file to ~/.config/tmux/scripts/battery.sh.

It shows dynamic icons and color-coded status.

#!/bin/bash
# ~/.config/tmux/scripts/battery.sh

# Catppuccin colors
GREEN="#a6e3a1"
YELLOW="#f9e2af"
PEACH="#fab387"
RED="#f38ba8"

# Get battery info
battery_info=$(pmset -g batt)
percentage=$(echo "$battery_info" | /usr/bin/grep -Eo '[0-9]+%' | head -1 | tr -d '%')

# Exit if no battery found
[[ -z "$percentage" ]] && exit 0

# Determine color based on percentage
if [[ $percentage -ge 50 ]]; then
    color="$GREEN"
elif [[ $percentage -ge 30 ]]; then
    color="$YELLOW"
elif [[ $percentage -ge 15 ]]; then
    color="$PEACH"
else
    color="$RED"
fi

# Check if charging
if echo "$battery_info" | /usr/bin/grep -q "AC Power"; then
    if echo "$battery_info" | /usr/bin/grep -q "charged"; then
        icon="󰁹"
        color="$GREEN"
    else
        icon="󰂄"
        color="$GREEN"
    fi
elif echo "$battery_info" | /usr/bin/grep -q "charged"; then
    icon="󰁹"
    color="$GREEN"
else
    # Discharging - choose icon based on level
    if [[ $percentage -ge 90 ]]; then
        icon="󰁹"
    elif [[ $percentage -ge 80 ]]; then
        icon="󰂂"
    elif [[ $percentage -ge 70 ]]; then
        icon="󰂁"
    elif [[ $percentage -ge 60 ]]; then
        icon="󰂀"
    elif [[ $percentage -ge 50 ]]; then
        icon="󰁿"
    elif [[ $percentage -ge 40 ]]; then
        icon="󰁾"
    elif [[ $percentage -ge 30 ]]; then
        icon="󰁽"
    elif [[ $percentage -ge 20 ]]; then
        icon="󰁼"
    elif [[ $percentage -ge 10 ]]; then
        icon="󰁻"
    else
        icon="󰁺"
    fi
fi

echo "#[fg=$color]$icon $percentage%"

The battery icon changes based on charge level. Ten different states. The color shifts from green to red as the battery drains. When charging, a lightning bolt icon shows up.

Plugins

I keep plugins minimal.

set -g @plugin 'tmux-plugins/tpm'
set -g @plugin 'tmux-plugins/tmux-sensible'
set -g @plugin 'tmux-plugins/tmux-yank'
set -g @plugin 'tmux-plugins/tmux-resurrect'
set -g @plugin 'tmux-plugins/tmux-continuum'

# tmux-resurrect
set -g @resurrect-capture-pane-contents 'on'
set -g @resurrect-strategy-nvim 'session'

# tmux-continuum (auto save/restore)
set -g @continuum-restore 'on'
set -g @continuum-save-interval '15'

The resurrect and continuum combo saves your entire tmux environment across system restarts. I use this every day.

Press prefix + I to install plugins.

Custom Session Scripts

I have three scripts to improve session management. These connect to tmux through keybindings in the config.

Save these in ~/.config/tmux/scripts. Run chmod +x ~/.config/tmux/scripts/* to make them executable.

# ~/.config/tmux/tmux.conf

# prefix + f: Open sessionizer (create/switch session from ~/Documents)
bind-key -r f run-shell "tmux neww ~/.config/tmux/scripts/tmux-sessionizer"

# prefix + s: Fuzzy session picker with pane preview (replaces default choose-tree)
bind-key s run-shell "tmux neww ~/.config/tmux/scripts/tmux-list"

# prefix + X: Fuzzy kill session(s) with pane preview
bind-key X run-shell "tmux neww ~/.config/tmux/scripts/tmux-kill"

The run-shell "tmux neww ..." pattern opens a new window to run the script. This keeps the fzf interface clean and full-screen.

Session Finder (prefix + f)

#!/usr/bin/env bash
# ~/.config/tmux/scripts/tmux-sessionizer

# Directories to search
SEARCH_DIRS=(
    ~/Documents
    ~/Projects
    ~/Code
    ~/dev
    ~/work
    ~
)

# Build find command for existing directories only
find_dirs() {
    for dir in "${SEARCH_DIRS[@]}"; do
        dir="${dir/#\~/$HOME}"
        [[ -d "$dir" ]] && find "$dir" -mindepth 1 -maxdepth 1 -type d 2>/dev/null
    done | sort -u
}

# Get existing tmux sessions
get_sessions() {
    tmux ls -F "#{session_name}|#{session_path}" 2>/dev/null | while read -r line; do
        name="${line%%|*}"
        path="${line#*|}"
        echo "[session] $name ($path)"
    done
}

if [[ $# -eq 1 ]]; then
    selected="$1"
else
    selected=$( (get_sessions; find_dirs) | fzf \
        --height 80% \
        --reverse \
        --header "Select directory or session" \
        --preview '...' \
        --preview-window "right:50%:wrap")
fi

[[ -z "$selected" ]] && exit 0

# Handle selection and create/switch session
# ... (session creation logic)

This script combines fzf with tmux to create a project launcher. Press prefix + f and you get a fuzzy finder showing:

• Existing tmux sessions
• Project directories from your configured paths

The preview pane shows directory contents (with git branch info) or session details (windows, panes, running commands).

Session List (prefix + s)

A cleaner replacement for the default choose-tree.

#!/usr/bin/env bash
# ~/.config/tmux/scripts/tmux-list

sessions=$(tmux ls -F "#{session_name}" 2>/dev/null)

echo "$sessions" | fzf \
    --height 80% \
    --reverse \
    --header "Sessions (Enter to attach)" \
    --preview '
        # Shows session info, windows, and panes
        # with colors and formatting
    ' \
    --preview-window "right:50%:wrap" \
    --bind 'enter:execute(tmux switch-client -t {})+abort'

Press prefix + s to see all sessions with a rich preview showing windows and panes.

Session Killer (prefix + X)

#!/usr/bin/env bash
# ~/.config/tmux/scripts/tmux-kill

sessions=$(tmux ls -F "#{session_name}" 2>/dev/null)

selected=$(echo "$sessions" | fzf \
    --multi \
    --header "Select session(s) to kill (TAB for multi-select)" \
    --preview '...')

echo "$selected" | while read -r session; do
    tmux kill-session -t "$session"
done

Multi-select support lets you clean up multiple sessions at once.

Shell Aliases

These aliases make tmux faster to use from the command line. I keep them in ~/.config/zsh/aliases.zsh.

# Tmux
alias t='tmux'
alias ta='tmux attach -t'
alias tn='tmux new -s'
alias tl='tmux list-sessions'
alias tk='tmux kill-session -t'

These single-letter aliases make common operations instant. Starting a new project session becomes tn projectname. Reattaching is ta projectname.

Quick Reference

Keybindings

Shell Aliases

Final Thoughts

This setup evolved over years of daily use. Here are the principles:

• Keep it keyboard-driven. Mouse support is nice. Efficiency comes from muscle memory.
• Make common actions fast. Session switching should be instant.
• Do not over-customize. Plugins should solve real problems. They should not add complexity.
• Persist everything. Never lose your work environment.

Take what works and adapt it to your workflow. The best tmux config is one you will use.

Configuration files available in my dotfiles repository.
